Penetration Grade Bitumen or Paving Grade Bitumen is a standard bitumen known as a crucial element for road construction and for the production of asphalt with superior qualities, which is very important once it bounds the aggregates and creates a unique cohesion and stability to the bituminous mix. This grade of Bitumen is mainly used in the production of hot mix asphalt for bases and wearing courses. Penetration Grade Bitumen supplied by Gayatram Pte Ltd  is petroleum-grade bitumen, manufactured from fractional / vacuum distillation of crude oil.

Characteristic Test Method Value
Specific Gravity @ 25/25°C ASTM D-70 1.01-1.05
Penetration @ 25°C (DMM) ASTM D-5 80-100
Softening Point(°C) ASTM D-36 45-52
Ductility @ 25°C (cm) ASTM D-113 100 min
Loss on Heating (%wt) ASTM D-6 0.2 max
Drop in Penetration after Heating (%) ASTM D-6 & D-5 20 max
Flash Point (°C) ASTM D-92 250 min
Solubility in CS2 (%wt) ASTM D-4 99.5 min
Spot Test A.A.S.H.O.T.102* Negative

Characteristic Test Method Value
Specific Gravity @ 25/25°C ASTM D-70 1.01-1.05
Penetration @ 25°C (DMM) ASTM D-5 80-100
Softening Point(°C) ASTM D-36 45-52
Ductility @ 25°C (cm) ASTM D-113 100 min
Loss on Heating (%wt) ASTM D-6 0.2 max
Drop in Penetration after Heating (%) ASTM D-6 & D-5 20 max
Flash Point (°C) ASTM D-92 250 min
Solubility in CS2 (%wt) ASTM D-4 99.5 min
Spot Test A.A.S.H.O.T.102* Negative
